WP Max-LoQ pF (GW) - ratiotherm Smart Energy Systems

Quick navigation:

Performance Range: 1,5 – 9,5 KW
Effizienz: COP up to 4,22 (W15/W30)

The advantages of the WP Max-LoQ pF series at a glance:

Equipped with natural refrigerant propane (R290, GWP 3)
Reliable operation thanks to high-quality components
Extremely quiet operation thanks to enclosed compressor
Best efficiency thanks to high coefficient of performance (COP)
Achieves a flow temperature of up to 72°C as a high-temperature heat pump
Ideal for use with groundwater and brine sources

Heating capacity	1,5 – 9,5 kW
Power consumption	0,3 – 2,4 kW
COP at rated capacity	4,22
Space heating energy efficiency	181,50 %

Cooling capacity	2,0 – 16,0 kW
Power consumption
EER at rated capacity	6,0 – 7,3 (provisional)

Type	Fully hermetic, rotary piston, inverter
Speed	940 – 5400 n/min
Max. operating current	16 A
Lock-up current LRA	– A

Type	Copper-brazed plate heat exchanger
Flow rate	0,5 – 2,5 m³/h
Test pressure	45 bar
Operating range	-196 – 200°C
Min. / Max. source temperature	-25 – 15°C

Type	Copper-brazed plate heat exchanger
Water flow rate	1 – 5,8 m³/h
Pressure drop	Max. 0,3 bar
Temperature difference	5 – 10 K
Test pressure	45 bar
Operating range	-196 – 200°C
Min. / Max. cooling temperature	25 – 68°C

Sound pressure level at a distance of 5 m	35 dB(A)
Sound power level	48 dB(A)
Dimensions	400 x 1510 x 615 BxHxT (mm)
Weight	170 kg
Max. operating pressure (water)	3 bar
Max. flow temperature	68°C

Power To Cool Ready ratiotherm Smart Energy Systems

Ready Glt Ratiotherm Smart Energy Systems Ratiotherm

Special features:

Propane R290 as a natural refrigerant

The WP Max-HiQ series is equipped as standard with the environmentally friendly and natural refrigerant propane R290. This refrigerant has a GWP value of 3 (GWP = Global Warming Potential). The heat pumps are designed with an integrated safety concept for safe system operation inside the building. All that is required is a ventilation opening to the outside.

Inverter control:

The WP Max-LoQ pF series can cover a very wide range of heating and cooling capacities thanks to the standard integrated speed control using inverter technology. This opens up a wide range of applications. The inverter technology also allows, for example, power regulation to use PV electricity for heating or cooling as required. This heat pump offers you maximum savings potential, as it always delivers the right output and automatically adapts to the current energy requirements of the living space in every season.
