Nahwärme-Wärmepumpe WP Grid-HiQ vom Hersteller ratiotherm

Performance Range: 2,5 – 30,7 KW
COP up to 3,77 (W10/W55)

The advantages of the WP Max-LoQ series at a glance:

Reliable operation thanks to high-quality components
Extremely quiet operation thanks to enclosed compressor
Best efficiency thanks to high coefficient of performance (COP)
Achieves a flow temperature of up to 72°C as a high-temperature heat pump
Ideal for use with groundwater and brine sources

	F06	F14	F21	F27
Heating capacity	2,5 – 7,5 kW	4,9 – 16,4 kW	6,5 – 20,8 kW	7,7 – 30,7 kW
Power consumption	0,66 – 2,2 kW	1,5 – 5,2 kW	1,9 – 5,9 kW	2,5 – 10,0 kW
COP at rated capacity	3,77	3,33	3,33	3,37

	F06	F14	F21	F27
Type	Fully hermetic, rotary piston, inverter	Fully hermetic, scroll, inverter	Fully hermetic, scroll, inverter	Fully hermetic, scroll, inverter
Blocking current LRA	32 A	40 A	45 A	50 A

	F06	F14	F21	F27
Brine flow rate	0,4 – 1 m³/h	0,8 – 2 m³/h	1 – 4 m³/h	1 – 4,5 m³/h
Pressure drop	0,2 bar	0,3 bar	0,3 bar	0,3 bar
Temperature difference	3 K	5 K	5 K	5 K
Min. / Max. source temperature	-5 bis 15° C	-5 bis 15° C	-5 bis 15° C	-5 bis 15° C

	F06	F14	F21	F27
Water flow rate	0,8 – 2,2 m³/h	1,2 – 2,5 m³/h	1,6 – 4,8 m³/h	1,6 – 5,3 m³/h
Pressure drop	0,2 bar	0,3 bar	0,3 bar	0,3 bar
Temperature difference	5 – 10 K	5 – 10 K	5 – 10 K	5 – 10 K
Min. / Max. flow temperature	25 – 72°C	25 – 72°C	25 – 72°C	25 – 72°C

	F06	F14	F21	F27
Sound pressure of indoor unit at a distance of 1 m	40 dB(A)	40 dB(A)	40 dB(A)	40 dB(A)
Dimensions of indoor unit	777 x 1800 x 512 BxHxT (mm)	777 x 1800 x 512 BxHxT (mm)	777 x 1800 x 512 BxHxT (mm)	777 x 1800 x 512 BxHxT (mm)
Weight	210 kg	230 kg	250 kg	270 kg
Max. operating pressure of water	10 bar	10 bar	10 bar	10 bar

Power To Cool Ready ratiotherm Smart Energy Systems

Ready Glt Ratiotherm Smart Energy Systems Ratiotherm

Special features:

Inverter control:

The WP Max-LoQ series can cover a very wide range of heating and cooling capacities thanks to the standard integrated speed control using inverter technology. This opens up a wide range of applications. The inverter technology also allows, for example, power regulation to use PV electricity for heating or cooling as required. This heat pump offers you maximum savings potential, as it always delivers the right output and automatically adapts to the current energy requirements of the living space in every season.
